DESCRIPTION
High-performance linear LED magnetic grille light features a multi-cell anti-glare louvre array designed for tool-free click-in installation into low-voltage magnetic track systems. Equipped with precision multi-faceted reflectors housed in deep-set black baffles, it delivers exceptional glare control (low UGR) and uniform direct illumination. Built with an extruded aluminum body for optimal passive heat dissipation, it is available in multiple length options to suit modular lighting layouts in modern office spaces, retail environments, galleries, and residential interiors.
TECHNICAL SPECIFICATIONS
| REFERENCE CODE | EK-30112 |
| MATERIAL | Aluminium |
| POWER (W) | 12W |
| LUMINOUS FLUX (LM) | 1326LM |
| COLOR TEMPERATURE (K) | 3000K-4000K-5000K |
| CRI | > 90 |
| IP RATING | IP20 |
| INPUT VOLTAGE (V) | AC220240V 50/60Hz |
| BEAM ANGLE | 24°/38°/50° |
| SIZE (MM) | L250*W23.5*H43mm |
| LIFESPAN (HOURS) | 50000 h |
| CERTIFICATION | CE |
